Xgrinder™ 3D Homogenizer
Xgrinder™: High-Performance Portable Homogenizer for Tough Samples
OnsiteGene's Xgrinder™ is a compact, high-speed 3D bead homogenizer engineered for efficient sample disruption and lysis. Its lightweight, portable design makes it an ideal tool for labs working with a wide range of sample types—including blood, tissues, plants, fungi, and Gram-positive bacteria.
Designed for seamless integration with the Xtractor™ system, Xgrinder™ enhances nucleic acid extraction workflows by delivering effective pre-processing and improved homogenization. This powerful combination boosts nucleic acid yield and purity, improving accuracy and efficiency in downstream applications—especially when handling challenging samples like fungi and Gram-positive bacteria.


Xgrinder™ Performance Advantage
The Xgrinder™ 3D grinding motion delivers the highest nucleic acid yield across all tested pathogens—including Gram-positive bacteria and fungi—outperforming vortex beating, enzymatic digestion, and 2D grinding methods. With a processing time of just ~4 minutes, Xgrinder™ significantly reduces workflow time compared to enzyme lysis (~15 minutes) while providing up to 4.3× greater yield.
In whole blood (WB) samples, Xgrinder™ achieved the lowest Ct values, indicating higher nucleic acid concentrations. The observed ΔCt improvements (ranging from 2.38 to 4.28) reflect substantial gains in extraction efficiency and pathogen detectability.
These results establish Xgrinder™ as the optimal tool for rapid, high-efficiency nucleic acid extraction, especially for tough-to-lyse organisms—making it ideal for time-sensitive diagnostic and research applications.

Key Product Highlights of Xgrinder™
-
3D Grinding Motion
Unique figure-8 oscillation for thorough and uniform homogenization. -
Ultra-Fine Grinding
Reduces particle sizes to ≤5μm — ideal for high-yield nucleic acid extraction. -
Flexible Grinding Modes & Multi-Sample Processing
Compatible with wet and dry grinding, and various tube formats. -
Versatile Sample Compatibility
Suitable for DNA, RNA, and protein extraction from diverse sample types. -
High Grinding Speed & Precision Control
Up to 5,500rpm, adjustable in 1 rpm increment, reaching target speed within 1 second. -
Advanced Shock Absorption
Dual-damping system reduces vibration for quiet, stable operation. -
Flexible Power Supply
Direct AC or 24V DC mobile power (e.g., power bank) for uninterrupted lab use. -
Compact & Lightweight
Only 5.3 kg in weight with a footprint of 240 × 240 × 240mm — portable and easy to store.

Xgrinder™ Instrument Specifications
Grinding Motion
3D motion mode with a figure-8 trajectory
Speed Range
0–5,500 rpm (adjustable in 1 rpm increments)
Sample Capacity
12×2 ml, 16×2 ml, 24×2 ml; 12×5 ml, 6×5 ml, 8×5 ml (customizable for specific experimental needs)
Particle Size Output
≤5 µm
Operating Conditions
Temperature 0–42 °C, Humidity 5–95%
Safety Features
Safety lock and automatic stop when the lid is open
Noise Level
≤ 62.4 dB(A)
Interface
Touchscreen with operational prompts
Programmable Settings
Grinding time (0–9999 sec), interval time (0–9999 sec), cycle count (0–99)
Custom Programs
Supports user-defined protocols
Program Storage
Up to 20 pgrograms
Weight
5.3 kg
Dimensions (W×D×H)
240x240x240 mm
Software
The software is designed for seamless and efficient operation. Integrated directly within the instrument, it features an intuitive interface for straightforward operation, allowing users to effortlessly customize grinding protocols. The software is also built to accommodate on-demand upgrades, ensuring that your system remains at the forefront of technology. For a comprehensive understanding of all the features and step-by-step guidance, users are encouraged to consult the detailed user manual.

Bead Tubes
Xgrinder™ Bead Tubes – Versatile, Pre-Filled, and Sample-Optimized
Xgrinder™ bead tubes are engineered for high-efficiency sample homogenization across a wide range of biological and environmental sample types. Each tube is pre-filled with optimized beads—ceramic, zirconia, stainless steel, or custom—tailored for specific sample properties, from soft tissues to hard materials.
Applications include:
-
Tissue & Biopsy Samples: Ceramic beads (BCT-1) for soft animal or plant tissues.
-
Bacteria (Gram+/-): Zirconia beads (BCT-2) for robust microbial cell disruption.
-
Fungi & Spores: Zirconia beads (BCT-3) for tough fungal walls.
-
Plant Materials: Ceramic beads (BCT-4) for roots, leaves, and seeds.
-
Hard Samples: Stainless steel beads (BCT-5) for bone, tooth, and wood.
-
Soil & Sediment: Mixed beads (BCT-6) for environmental samples.
-
Fecal Samples: Zirconia beads (BCT-7) optimized for stool.
-
Custom Needs: BCT-8 for user-defined bead configurations.
Key Features:
-
Pre-filled and ready-to-use (no pre-processing required)
-
Autoclavable and DNA/RNA-free certified (optional)
-
Available in 2 mL and 5 mL volumes for flexible input
